Wednesday, November 30, 2016

Pinecone Coloring Sheet - and using LucidPress

This is my first experiment using LucidPress.

Here's My Pinecone Coloring Sheet.

  • You're welcome to download and print
  • Find the spirals and color using highlighters

This is a fun activity as part of a lesson on pinecones, patterns and fibonacci math for preschoolers and up!

Learning with Pinecones

Learning with Pinecones
Today was drizzling. As I walk with preschoolers we listen to rain, step in puddles and admire raindrops cascading off a roof. We pass a couple of tall pine trees and check out the bundles of needles littered on the grass. Count the needles in each bundle: some have three, four, or five needles. The pines are Eastern White pines that have up to five needles in a bundle. We look for pinecones too. I have setup our class in a gazebo - where we continue to listen to the rain and can be sheltered.

Observation
A selection of pinecones to pass around, touch, lift and smell engages the young learners. The pinecones smell of resin, some are sticky, others prickly. The Coulter pinecone is huge, spiky and incredibly heavy and resiny. The sugar pinecone is light and long. The Jeffrey pinecone is also huge, and surprisingly strong yet light. For each pinecone we can see where the seeds grow and are protected - and have fallen out. Bring a pineapple and a dried sunflower flowerhead to highlight the similar fibonacci spiral patterns. I also bring in another different seedhead: one from a “bobbletree” - Liquidambar to compare and contrast with the pinecones patterns. This helps set the scene for an appreciation of patterns and diversity.


Coloring as prelude to journaling
I leave a medium-sized pinecone in the table of the table and give students the My Pinecone coloring sheet.

Observe the spirals on the drawing sheet.
With highlighters I encourage the students to highlight the spirals in one direction. Then we pick a different color highlighter and try to find and color the spirals going in the opposite direction.
The preschoolers enjoy writing their names on the sheets too. Coloring can be trendy therapy, it is also a first step to future journaling.




Decorating pinecones to take home
I have collected small pinecones from a Virginia pine tree (the State Virginia pine tree) - that fell in a storm a few winters ago. Each year I collect a few more from other trees in the neighborhood.
Students decorate a small pinecone using glitter glue. Taking time with the brush and glue is fun and enhances the sensory experience. The pinecones take a day to dry. Students can take home as a gift from the garden to enjoy as a seasonal sparkly winter decoration, and reflect on the patterns they’ve experienced in nature!

We go back to class stomping in the puddles and looking at the clouds!

Resources

Pinecone coloring sheet - download, print and color http://www.slideshare.net/MaryVanDyke/my-pinecone-coloring-sheet-greenstem

Sunday, November 20, 2016

WOW factor: How to Grow Bulbs Indoors and Out


With our winter season fast approaching it is time to plant some spring flowering bulbs indoors and out.

Here's the link to my current lesson plan on planting paperwhites

Here are how-to's from my blog piece of February 2016. How about planting some fragrant Paperwhites or Hyacinths to brighten up your class? Or buy Journey North's Red Emperor Tulips and plant outdoors? You can track and log the tulip's growth and bloom-time as part of an easy citizen science project.


  • Crocuses, daffodils and snowdrops are appearing in the schoolyard through the melting snow.

  • crocus

  • Do you love or hate the scent of Paperwhite narcissus and Hyacinths that you can grow indoors over winter?


  • Why and how do these plants grow shoots?

  • daffodils

  • Observation and inquiry about flowering bulbs can be a great gateway introduction to plants and plant lifecycles throughout K- 5th grade.

  • Growing flowering bulbs is an appealing, fun nature-themed project for the winter months.

  • Introduction to Bulb Biology

  • Here’s a 7-minute video introduction to bulb biology for a 2nd - 5th grade audience, that I made with Nicole Schofield 5th Grade teacher at Jamestown and filmed by Yorktown High School student, Stephanie Schofield - LINK

  • These are easy 5E steps for a lesson on bulb biology and bulb planting

  • Engage: Cut carefully through a spare tulip bulb or red onion in class and you can clearly see that a bulb is modified leaves. You may see the central shoot that will have flowers and if pollinated will produce seeds.

  • tulip crosssection

  • Check out the basal stem and roots.

  • red onion

  • Use the Journey North diagram to teach your class the parts of the bulb.


  • Explain

  • How does the plant work? The sun shines on the plant, and with chlorophyll and CO2, the leaves convert the sun's energy into food (carbohydrates) through the process of photosynthesis - and the plant gives off O2. The roots carry water and nutrients into the plant so it can produce flowers, seeds and reproduce. The bulb is the plant's tissue structure (modified leaves) that stores energy for the plant as the above-ground leaves die back.


  • Elaborate

  • Learn about dormancy. The bulb is dormant (not dead) and usually needs to go through a real or artificial winter to promote growth.

  • Now plant some bulbs indoors or out.

  • Here’s some choices of bulbs and how-to’s to optimize your project for successful flowering.

  • red tulip

  • Journey North Tulip Test Gardens - outdoor planting

  • For planting outdoors, growing a Journey North Tulip Test Garden is an easy citizen science project for ages K and up.

  • You need to buy Red Emperor tulip bulbs.

  • The Red Emperor tulip bulbs may cost a little more per bulb than other cultivars, but buying Red Emperor bulbs allows you to then leverage the educational linkage to the Journey North citizen science project. That is extra teaching value that may be worth the extra cost!

  • Here’s a movie from APS GreenScene about planting Journey North Tulips with 3rd Grade students from Carlin Springs talking about the benefits - LINK

    • By recording the planting and flowering dates on the website, students contribute data that can be used to track climate change.

  • Growing bulbs in the ground outside has advantages, in that the bulb goes through natural winter cycle and will shoot in the spring.


  • Here below Kindergarten students plant tulips in raised beds at Jamestown.

  • I use string, stake and tape to mark the planting place for each student. The students are using their trowels to the measure correct planting depth.

  • kindergarten planting tulips


  • Container planting outdoors

  • At Jamestown, the 5th grade gardening team plant Tulips and Daffodils in big planters outside the front entrance and the trailers.

  • planting tulips in container bulbs in container

  • However if you grow bulbs in outdoor planters and containers you need to make sure the bulbs are not too cold - since the bulbs could die if over-frozen.

  • In early January, I wrap the containers with layers of newspaper and cover the layers with burlap and tie securely with string. Will that be enough insulation to keep the bulbs as warm as if they had been in the ground? I will need to unwrap the containers so the plants can continue to sprout later in the spring.

  • Why are tulips and daffodils OK when planted in the ground? The bulbs may be dug up by rodents and squirrels when outdoors, but they will at least be kept warm with the earth's geothermal heat provided you planted the bulbs deep enough, and ground is not too cold for them! As with most outdoor experiments there are a lot of variables. It is difficult as a gardener to control for all of them!

  • Planting bulbs indoors

  • For students to plant a bulb each, try Paperwhite narcissus bulbs with low scent (to reduce risk for people sensitive to the smell) e.g. I select the cultivar Inbal.

  • paperwhite


  • You can buy Paperwhite bulbs before Thanksgiving, and plant them in class before the winter holiday. Then students can take their potted bulb home as a winter gift and look after their plants during the holidays. Or you can aim to store the bulbs in a cool/dark place and then plant them with your class in early January, so students can then take the bulbs home and care for the plants during January and February.

  • The 5th grade classes planted their paperwhite bulbs in a big pot or a customized clean milk carton - with drainage holes. Both ways worked in my parallel experiments.

  • paperwhites paperwhite


  • Hyacinth bulbs - growing indoors over water

  • For a class demo, in addition to each student growing a paperwhite at home, you can also grow a "class" Hyacinth bulb on a light window cill or in a very light place at school.

  • The Hyacinth bulb as bought, will need to have already gone through an artificial winter in order to grow and flower.

  • Or you will need to keep the Hyacinth bulb in the fridge in paperbag to chill the bulb but not freeze it for a few weeks (say 9 weeks). Then you can place the bulb on a vase of water, just below the basal stem and begin to watch the roots grow in the fridge first for a few days.

  • bulbs in fridge

  • Then move the bulb and vase out to a light window cill. Keep the water refreshed and just below the basal stem.

  • Hyacinth bulbs

  • Grown hydroponically over water, is a wonderful way for students to see the speed  of growth and spread of the root system.

  • Students can see the Hyacinth's roots growing measurably every day. As the plants grow, transfer the hyacinth bulbs from small vase to clean quart size recycled juice jars. Be careful of the delicate root system!

  • hyacinth bulb close up

  •

    • Link science and Language Arts and have students write a My Hyacinth Story.

  • Hyacinth from Ms Schofield

  • When your bulbs flower

  • Take a lesson to study flower parts using your bulbs when they are flowering as demonstrations.

  • Name and count and draw: petals, sepals, stamens, pistil.

  • daffodil

  • Monocots and Dicots

  • All the bulbs: hyacinths, narcissus (paperwhites, daffodils, tete a tete) snowdrops, crocus, amaryllis, iris have “straplike veined leaves" and are monocots. Monocots have seeds with one food part, mono-cotyledon. Note the symmetry of the monocot’s flowers - it is symmetry of 3 with 3 or 6 petals or three petals. Grasses are also monocots

  • Dicots include plants such as beans with seeds with two food parts, di-cotyledon.  Early spring flowers such as spiraea, early blooming forsythia, aquilegia, apples and cherries are dicots. You can see the flowers symmetry will be 5 or 8 (but not 3) and the leaves of dicots are veined.

  • For this lesson, you can bring in an asssortment of flowers and have students study and sort them into monocots and dicots.

  • studying flowers

  • In summary here are some activities for students to do while their bulb plant grows:

    • Before you plant your bulb weigh it and measure its circumference

    • Track your plant’s  growth and development

    • Record the growth in an album, science notebook or on a googleform

    • Report your data for Journey North Tulips on their website

    • When did your plant flower?

    • Was the flower pollinated?

    • Did the flower produce seeds?

    • When does the plant die back?

    • After the plant has died back - dig it up and recheck the weight and measure its circumference, compare with your previous measurements.

  • Have fun labeling your bulbs too. If you plant your bulbs outside in the schoolyard, labeling the planting spot is good PR for the rest of the school and then you won’t forget where you planted them. Here are some simple labels made with googlepresentation and photocopied onto Xerox polyester paper.

  • tulip project labels

  • Good Luck with your flower bulb planting projects, indoors and out.


  • Enjoy the flowers beauty and wow factor.


  • Now is a good time to plan the time for this project in your schedule for next fall, and to budget for the project supplies.


  • Reposted from the former Arlington Public Schools ATS Gardening Blog

  • By Mary Van Dyke, 2/3/2016


As a postscript:
The tulips and daffodils in the wrapped containers - did really well.
I unwrapped the planters when the weather warmed, and the flowers looked great at the front entrance of the school, blooming in successsion for a really long time in the spring.


NOTE: I now use TerraSlate 'non-wood waterproof paper' in 7 mm or 10 mm to make outdoor signs and labels for schoolyards.

I am about to redo these bulb-planting class projects with K (Journey North Tulips) and 5th Grade (Paperwhites and Hyacinths).

I am wondering if the tulip and daffodil bulbs in the planters have survived over the summer and may rebloom in the spring too?
